Guide on How FRED Handles Polarization



In our optical setup, we begin with a polarizing beam splitter. Here's how FRED manages polarization:

  • Polarizing Beam Splitter: Light is directed to the beam splitter, where it's reflected towards a mirror.
  • Quarter Wave Plate: The light passes through a quarter wave plate before returning and striking an analysis surface.

    • Running a ray trace reveals the path of the rays through reflection, transmission via the wave plate, and back to the analysis surface.

    To analyze polarized light behavior, follow these steps:

  • Check Polarization Spot Diagram: Examine the polarization spot diagram on the end ray surface.
  • Click "OK" to observe the behavior of polarized light.

    • Through these steps, FRED effectively manages and visualizes polarization behavior in optical systems. Experiment with different setups to gain deeper insights into polarized light phenomena.

    If you have more specific questions regarding this process, feel free to reach out to our support email support@cbseu.com for assistance.
